Polymerase chain reaction (PCR) is a simple and inexpensive technique to make multiple copies of a targeted nucleotide sequence from a DNA sample and to amplify sequences from small samples. This technique is widely used in genetics laboratories that work with DNA and RNA.
Because PCR amplification is extremely sensitive to contamination, prevention of contamination requires good laboratory practices to minimize external or cross-contamination during reagent preparation, sample preparation and sample amplification.
Benefits:
Provides sterile work zone for aseptic techniques.
Air cleanliness meets and exceeds ISO Class 5.
Energy saving LED lighting.
Vertical laminar airflow with HEPA filtration.
Equipped with germicidal UV lamp to create light emission conditions known to provide safe decontamination.
360 degree visibility with UV absorbing polycarbonate construction.
Purair PCR cabinets are available in three model sizes with various options.
Designed for desktop use or installation on an optional base stand or mobile cart.
Product Features:
A. Control Panel: The integrated control panel features an On/Off switch for the fan, light, and UV lamp timer.
B. Main Filter: Main HEPA filter with 99.99% efficiency for 0.3 micron particulates.
C. Pre-Filter: The pre-filter can be changed while the unit is operating to prevent operator exposure to chemical vapors.
PCR workstation callouts
Purair PCR-24, shown with optional mobile cart and optional stainless steel work surface.
D. Fan: High-performance ebm-papst EC fan.
E. Stand: Optional base stand converts to mobile cart with optional locking casters.
F. Lighting: Compact LED cabinet lamp located away from laminar flow area.
G. UV Lamp: Built-in ultraviolet lamp with timer creates light emission conditions known to permit safe decontamination between PCR cycles.
H. Pass Through Ports: Convenient rear wall pass-through ports for safe routing of instrument cords, cables, and leads.
I. Filter Door Lock: Prevents unauthorized removal or accidental exposure to dirty filters.
J. Ergonomic Design: Ergonomically angled front improves reach and user comfort.
K. Work Surface: Large polypropylene work surface, white or black standard with optional stainless steel work surface available.
L. Decontamination Shelf: Mounted on the back wall near the UV lamp for maximum exposure.
M. Magnetic Door Latch: Safety interlock prevents operator exposure to UVs when door is opened during decontamination cycle.
N. Double-Hinged Self-Locking Front Sash: The magnetic sash closure protects samples on the work surface from contamination with up to 90 fpm airflow.
