At IDE we have available the new, FDA-cleared CLC6410 from Carolina Liquid Chemistries is a high volume, modular modular clinical chemistry analyzer. The CLC6410 is capable of meeting the needs of large hospitals and clinical reference laboratories with an economical, modular design that allows laboratories to expand its throughput as their needs grow. A single module can run up to 1600 tests/hr, while four modules can be joined to achieve 6400 tests/hr. All configurations include a 300 sample loader and intuitive software that automates numerous operational and quality control procedures. The CLC6410 also features technological advances that save time, water, and energy.
System Type:Random access, fully automatic, discrete, STAT priority
Throughput:Constant speed 6400 tests/hour colorimetric (integration of 4 modules)
Max. ISE throughput up to 960 tests/hour
Light Source:Long life halogen lamp
Wavelength:340-800nm, 13 wavelengths
Analysis Method:End-point, kinetics, fixed-time, turbidimetric
Calibration Method:1 point method, 2 point method, multiple point linear method, non-linear method
Probe:Independent sample probes, reagent probes, automatic liquid level detection,
probe liquid level sensing and clot detection function
Rinsing Mechanism:Probe inner wall high pressure rinsing
Mixing Mechanism:2 sets independent mixers for each module ensure sufficient reaction
Reaction Cuvette:330 reaction cuvettes for each module
Temperature Control:Reaction disk incubation bath temperature is 37ºC ± 0.1ºC
Reagent Position:134 reagent positions for each module; 67 2-part reagent tests
