Features:
1. 49 Sample positions.
2. 56 Reagent positions.
3. 120 Reaction cuvettes.
4. 200 Tests per hour.
5. Probe with anti-collision function,liquid level dectection function.
1. 49 Sample positions.
2. 56 Reagent positions.
3. 120 Reaction cuvettes.
4. 200 Tests per hour.
5. Probe with anti-collision function,liquid level dectection function.
Specification
|
Model
|
BK-280
|
|
|
Overall
Performance |
Throughput
|
200Tests/Hour
|
|
Analysis Method
|
End-point, Fixed-time, Rate(Kinetic), Turbidimetry
|
|
|
Sample & Reagent Unit
|
Sample Positions
|
49 sample positions
|
|
Reagent Positions
|
56 reagent positions
|
|
|
Sample Volume
|
2-70μL
|
|
|
Reagent Volume
|
20-350μL
|
|
|
Probe
|
Teflon coating, with anti-collision function,liquid level detection function
|
|
|
Probewashing
|
Automaticwashing interior and exterior
|
|
|
ReagentCooling
|
Refrigerated tray with independent switch
|
|
|
Reaction System
|
Temperature Control
|
37±0.2℃
|
|
Cuvettes
|
120 reusable cuvettes,optical length 6mm
|
|
|
MixerProbe
|
Independent stirring
|
|
|
Washing
|
Automatic cuvettes washing
|
|
|
STAT function
|
YES
|
|
|
Optical System
|
Light Source
|
12V/30W halogen lamp
|
|
Spectrophotometry
|
Post-spectral spectrophotometry
|
|
|
Wavelength
|
340,405,450,480,505,546,570,600,630,700,750,800nm
|
|
|
Absorbance
|
0~3.0Abs
|
|
|
Calibration&QC
|
Calibration
|
Linear: K factor, 1-point, 2-point and multipoint linear
Non-Linear: Spline, Polygon, Index, Ogarithm, Logit-4P,Logit-5P |
|
Quality Control
|
Real-time QC, Westgard multi rule, Cumulative sum check, Twin Plot(2D)
|
|
|
Data Management
|
Software
|
Windows 7/8/10, 32or64 bit
|
|
LIS System
|
Bi-direction, support HL7 protocol
|
|
|
Interface
|
LAN port access
|
|
|
Printer
|
External, multiple reporting mode available
|
|
|
Working Conditions
|
Power Supply
|
AC220V±10%, 60/50Hz,, 110V±10%, 60Hz, 300W
|
|
Temperature
|
10～30℃
|
|
|
WaterConsumption
|
Deionized water:5L/H
|
|
|
Humidity
|
40-85%
|
|
|
Size & Weight
|
External Size (W*D*H)
|
950*603*510mm
|
|
Net Weight
|
65kg
|
|
|
Package Size(W*D*H)
|
1085*700*1012mm
|
|
|
Gross Weight
|
140kg
|
|
