Thermo Microm HM550 VP Cryostat: Refurbished

MANUFACTURER

THERMO SCIENTIFIC

MODEL

MICROM HM 550 VP

CAT. NO.

956464

SERIAL NO.

29926

CHAMBER TEMPERATURE CONTROL

-10°C TO -35°C

SPECIMEN TEMPERATURE CONTROL

+10°C TO -50°C

FINE SECTIONING THICKNESS

1 TO 100 UM

TRIM SECTIONING THICKNESS

5 TO 500 UM

HORIZONTAL FEED

28MM

VERTICAL STROKE

60MM

FAST FREEZING STATION DEPENDING ON THE CHAMBER TEMPERATURE

UP TO -35°C

ACTIVELY COOLED FAST FREEZING STATION WITH PELTIER ELEMENT

MAX. UP TO -60°C

DEFROSTING

AUTOMATIC DEFROSTING, ADJUSTABLE WITH TEMPERATURE CONTROL
MANUAL IMMEDIATE DEFROSTING

1 TO 100 ΜM RESOLUTION

1 UM FROM 1 TO 10 UM
2 UM FROM 10 TO 20 UM
5 UM FROM 20 TO 70 UM
10 UM FROM 70 TO 100 UM

TRIMMING THICKNESS RANGE

5 TO 500 UM

5 TO 500 ΜM RESOLUTION

5 UM FROM 5 TO 10 UM
10 UM FROM 10 TO 100 UM
20 UM FROM 100 TO 200 UM
50 UM FROM 200 TO 500 UM

SPECIMEN RETRACTION DURING RETURN TRAVEL

40 UM

VERTICAL SPECIMEN STROKE

60 MM

HORIZONTAL SPECIMEN MOVEMENT

28 MM

SPECIMEN APPROACH

AUTOMATIC FUNCTION
ALTERNATIVELY MANUAL WITH VARIABLE SPEED

SIZE OF CHUCKS

30 AND 40 MM
SPECIAL SIZES UPON REQUEST TO MANUFACTURER

SPECIMEN ORIENTATION

X- AND Y-AXES: UNIVERSAL 8° WITH ZERO POSITIONING
Z-AXIS: UP TO 360°

COARSE FEED

MOTORIZED, GRADUATED, SINGLE AND CONTINUOUS

SLIDING WINDOW

HEATED

COOLING CHAMBER ILLUMINATION

WITH VARIABLE ILLUMINATION POSITION

DIMENSIONS (W/O HANDWHEEL) (W X D X H)

30” X 25” X 47” (64 X 76 X 120 CM)

POWER REQUIREMENTS

115V, 60HZ, 12A

OPTION V

MAX. SPECIMEN SIZE

28 MM

MAX. SECTION THICKNESS TO BE DISPOSED OF

MAX. 40 UM

MAX. SECTION THICKNESS TO BE STRETCHED

20 UM

MIN. SECTION THICKNESS TO BE STRETCHED

1 UM

CLEARANCE ANGLE ADJUSTMENT

STANDARD KNIFE CARRIER: 5 TO 16°
DISPOSABLE BLADE CARRIER: 5 TO 16°
MAGNETIC DISPOSABLE BLADE CARRIER: 25 TO 30°

COARSE FILTER

GLASS FIBER REINFORCED EXTRACTION THIMBLE

MICRO FILTER

BOROSILICATE MICRO FIBER
99.99% FILTRATION EFFICIENCY FOR 0.1UM PARTICLES
