Hoffman LWC239316SS, Inst. Box, Hinged Window Cvr, Type 4X, 230x930x155mm

Hoffman LWC239316SS, Inst. Box, Hinged Window Cvr, Type 4X, 230x930x155mmConsolets are ideal for mounting small control or instrumentation devices where the desirable access requires a 30- or 60-degree surface. These enclosures can be mounted on either of two sides for placement on desktops, pedestals or other flat surfaces. See the HMI chapter for related mild steel consolets.Features:Type 304 stainless steelSeams continuously welded and ground smoothCaptivated cover screws thread into sealed wellsCover attached with continuous hingeOil-resistant gasketBonding provision on door Product Specifications BRANDHoffman® MANUFACTURERS PART NUMBERLWC239316SS TYPE4X CONSTRUCTIONSS Type 304 STEEL PANEL-- CLEAR SPACE ABOVE PANEL INCHES5.51 CLEAR SPACE ABOVE PANEL MM140 MOUNTING G X H MM-- WINDOW N INCHES34.42 WINDOW N MM874 MOUNTING G X H INCHES-- DESCRIPTIONOptional Components Selection Guide PANEL SIZE D X E (MM)-- A X B X C MM230 x 930 x 155 CONDUCTIVE PANEL-- PANEL SIZE D X E (INCHES)-- A X B X C INCHES9.06 x 36.61 x 6.10 MTG. STUDS J INCHES34.67 MTG. STUDS J MM881 MTG. HOLES H INCHES35.29 MTG. HOLES H MM896 ENCLOSURE B INCHES36.42 ENCLOSURE B MM925
