The PV Chargers Modular S4850G1 is a high efficiency DC/DC
conversion module that has the maximum power point track
(MPPT) function and provides -48 Vdc output.
It tracks the highest solar power point based on the output
features of PV modules to maximize the use of solar energy. The
S4850G has been qualified by TUV and CE certifications.
The S4850G1 converts the DC power into stable output and provides the function of
maximum power point tracking (MPPT). The MPPT function adjusts the S4850G1 operating
status and enables it to work at maximum power output.
maximum power point tracking (MPPT). The MPPT function adjusts the S4850G1 operating
status and enables it to work at maximum power output.
Specifications
|
Model
|
S4850G1
|
|
size
|
39*17*10cm
|
|
weight
|
2.1kg
|
|
input
|
58-150v
|
|
output
|
53.5v-0-50a
|
Products Description
Introduction
Features
High efficiency: >98%, facilitating huge energy saving
Modular design: compatible with 50A rectifiers with Huawei power
frames
Wide operating temperature range:－20℃ to ＋75℃ ( can startup
@ －40 ℃ with light load(20%) after heating for 20 minutes)
Hot-swappable PV charger
CAN communication
Night standby power consumption ≤ 1.2 W, further saving energy
Adjustable voltage and current
Built-in fan: the speed of fan depends on the internal temperature
Modular design: compatible with 50A rectifiers with Huawei power
frames
Wide operating temperature range:－20℃ to ＋75℃ ( can startup
@ －40 ℃ with light load(20%) after heating for 20 minutes)
Hot-swappable PV charger
CAN communication
Night standby power consumption ≤ 1.2 W, further saving energy
Adjustable voltage and current
Built-in fan: the speed of fan depends on the internal temperature
