Keyence OP-84388 safety module Relay board for SL-T11R

Model

SL-T11R

Combined light curtain

SL-V Series

Output

FSD1、2

230 VAC/4 A, 30 VDC/2 A (Resistance load)
230 VAC/2 A (COSø = 0.3) (Inductive load)
30 VDC/1 A (COSø = 0.3) (Inductive load)^*1

Life-span

Mechanical life: 10 million cycles or more/Electrical life: 0.1 million cycle or more^*1

Response time (ms)

ON→OFF

+6 ms

OFF→ON

+15 ms

Approved standards

EMC

EMS

UL61496-1, IEC61496-1, EN61496-1

EMC

FCC Part15B Class A, ICES-003 Class A, EN55011 Class A

Safety

UL61496-1, IEC61496-1, EN61496-1 (Type 4 ESPE), ISO 13849-1: 2015 (Cat 4 PLe), UL508, EN50178

Rating

Power voltage

24 VDC ±10 %, Ripple (P-P) 10 % or less

Current consumption

100 mA or less (at 24 VDC, SL-T11R alone)

Environmental resistance

Enclosure rating

IP20 (IEC60529), Set inside control panel with IP54 or more

Pollution degree

2

Overvoltage category

III

Ambient temperature

-10 to +55 °C 14 to 131 °F (No freezing)

Storage temperature

-25 to +60 °C -13 to 140 °F (No freezing)

Relative humidity

15 to 85 % RH (No condensation)

Storage relative humidity

15 to 95 % RH

Vibration resistance

10 to 55 Hz, Double amplitude 0.7 mm 0.03", 20 sweeps in each of the X, Y, and Z directions

Shock resistance

100 m/s² (Approx. 10 G), 16 ms pulse, 1,000 times in each of the X, Y, and Z directions

Material

Polycarbonate

Weight

Approx. 330 g
