Convection cooled – inaudible
Accepts 85 – 300 VAC/DC input
12, 24-30, 48 VDC output versions
NiCad support for 12 and 24VDC
Quick-trip pulse to help open load MCB
Pot-meter voltage adjustment for
standalone
Module alarm relay contact for basic
monitoring without controller
Active current sharing
Comprehensive monitoring and control when used with controller:
* Remote/local connection through Ethernet
* Webpages and SNMP support
* Monitoring of rectifier temperature,
input voltage and output current
Modular approach in DIN-rail
mountable back planes
Off-the-shelf delivery
