Leeson 170041.60, Premium Eff., 50 HP, 3565 RPM, 208-230/460V, 326TS, TEFC, Rigid

General Purpose, 3-Phase Motor: 50/40HP, 3565/2965 RPM, Totally-Enclosed Fan-Cooled (TEFC) Enclosure, 326 Frame, Rigid Mount, 208-230/460V, 3PH, 60/50HZ, Name Plate Amps 123 - 111/55.5&100/50, Continuous duty, 1.25 Service Factor, No thermal protection, Efficiency: 94.5, Efficiency Type: NEMA Premium, Ambient 40 C, Reverse Rotation.Totally enclosed fan cooled (TEFC) enclosure has no vent openings, and is tightly enclosed to prevent the free exchange of air, but is not airtight. An external fan is an integral part of the motor and provides cooling by blowing air around the outside frame of the motor. Suitable for use where exposed to dirt or dampness, but NOT very moist or hazardous (explosive) locations.Rigid base allows motor to be rigidly mounted on equipment. Product Specifications HORSEPOWER50 ENCLOSURETEFC FRAME326TS MOUNTINGRigid NAMEPLATE RPM3565 PHASE3 MOTOR RPM 60Hz3565 VOLTAGE208-230/460 HERTZ60/50 DUTYContinuous SERVICE FACTOR1.25 THERMAL PROTECTIONNo EFFICIENCY TYPENEMA Premium EFFICIENCY94.5 AMBIENT TEMP C40 ROTATIONCCW/CW WEIGHT564 ULY CSAY LEESON MODEL NO.C326T34FB4DD UPC69172002801 RPM RANGE3001-3600 COMPATIBLE WITH/REPLACES - 1Baldor EM4114T, WEG 05036ET3E326TS, Marathon E976A COMPATIBLE WITH/REPLACES - 3Grainger/Dayton, 4FM55, 4N919, 4N929, 4N946, 5N270, 5N830 BEARING-DRIVE-END6312 COMPATIBLE WITH/REPLACES - 2TechTop GR3-CI-TF-326TS-2-BR-D-50 FL AMPS123 - 111/55.5 BRANDLeeson MANUFACTURER PART #170041.60 is_motorYes DESIGNSq Cage Inductor Run ENCLOSURE TYPETotally Enclosed FRAME MATERIALCast Iron
