Description
Head
- Dual diopter adjustments accommodates different eye focal length
- Parfocality maintained between magnifications
- Clearly marked neural knobs for magnification
- 10X super-widefield eyepieces with interpapillary and diopter adjustments to correct for user-specific eyesight
- Parfocal zoom optics
- Trinocular photo port for attachment of camera
- Image selection knob to send image to camera or eyepieces (will loose one ocular with imaging through camera)
Stand
- 25.4cm (10 in.) of focusing travel on continuous gear
- Sturdy focusing mechanism with no side-to-side movement (sturdier then pole)
- Smooth focusing travel
- Easily move between small and large size samples
- Textured, non-slip surface
- Large working surface of 21.8 x 30.2cm
- Stable working platform
- Ergonomically contoured, low profile base allows for comfortable arm support
- Auto-switching power supply works with 100V to 240V
- Diascopic transmitted illumination for contrast of transparent samples
- Recessed opening for up to 100mm size petri dishes for darkfield illumination
- Floating stage to move sample around in Darkfield well
- Capacitive touch light control panel allows for easy switch between light techniques and brightness control
- Removable, dual LED light guides with interchangeable wavelength specific LED's
- Interchangeable nose piece allows for optional LED ring lamp for white light or fluorescence
Lighting
- 120 Watt equivalent, wavelength specific, LED transmitted ring illuminator for GFP, RFP, DAPI and diascopic illumination creates homogenized brightness through field of view
- Individual 50 Watt equivalent, dual light guides for bi-directional illumination adjustment
Dimensions
- D x W x H: 39.2 x 43 x 38.5cm (15.2 x 16.9 x 15.1 in.)
Certifications
Quality Performance Certification
