Specifications:
Output Power: 0.25 mW minimum, 0.35 mW typical
Note: A green HeNe will appear 4 times as bright as a red HeNe of the same output power.
Wavelength: 543.5 nm GREEN
Polarization: Linear, >500:1
Mode: TEMoo
Beam Diameter: 0.77 mm
Beam Divergence: 0.90 mRads
Aperture Mount: 4x 4-40 tapped holes 1" Square spacing
Operating Voltage: 2390 VDC
Start Voltage: 10 KV
Operating Current Range: 6.5 mA +/- 0.2mA
Input Leads: Male Alden connector with 9 inch cord.
Dimensions: 15.6" long x 1.75" diameter.
| Condition: | Used. |
|---|---|
| Brand: | Melles Griot | MPN: | 05-LGP-151 |
| Model: | 05-LGP-151 | Country/Region of Manufacture: | United States |
One Year Warranty
