Marathon Motors Metric Motor, R363, 63T34Fh5404, 1/3-.25Hp, 3600Rpm, 230/460V, 3Ph, 63 Fr, Tefc

Marathon Motors Metric Motor, R363, 63T34FH5404, 1/3-.25HP, 3600RPM, 230/460V, 3PH, 63 FR, TEFCMarathon's line of Metric Dimension Motors are designed in IEC Frames from D63 through D200L. The motors are available from stock in 50 Hz or 60 Hz. This means that replacement 60 Hz motors are readily available from Marathon to replace metric motors. Product Specifications HORSEPOWER1/3 ENCLOSURETEFC FRAME63 MOUNTINGRigid NAMEPLATE RPM3600 PHASE3 MOTOR RPM 60Hz3600 VOLTAGE230/460 DUTYContinuous SERVICE FACTOR1.15 AMBIENT TEMP C40 WEIGHT30 ULRecognized Construction CSAY RPM RANGE3001-3600 MODEL NUMBER63T34FH5404 BEARING-DRIVE-ENDBall 60 HERTZ kW0.25 BEARING-OPP-DRIVE-ENDBall FL EFFICIENCY72 Percent INSULATION CLASSF FL AMPS1.1/.55 50 Hertz HP1/3 50 Hertz kW0.25 50 HERTZ RPM3000 KVA-CODEJ APPROVAL-CEY NEMA DESIGNB ASSEMBLYF3 STARTING TYPELine or Inverter 50 HERTZ VOLTAGE200/400 50 HERTZ FL AMPS1.3/.65 BRANDMarathon Motors 50 Hertz SF1.15 MANUFACTURER PART #R363 ORIENTATIONHorizontal is_motorYes IP CODE55 ENCLOSURE TYPETotally Enclosed
