Baldor-Reliance Motor EM4108T, 30HP, 3520RPM, 3PH, 60HZ, 286TS, 0954M, TEFC, F

Baldor-Reliance Motor, 30HP,3520RPM,3PH,60HZ,286TS,0954M,TEFC,FFeatures:Ball bearingsSuitable for mounting any positionHeavy gauge steel and cast iron framesTypical Applications:Pumps, compressors, fans, conveyors, machine tools and other applications where three phase power is available. Product Specifications HORSEPOWER30 ENCLOSURETEFC FRAME286TS MOUNTINGRigid NAMEPLATE RPM3520 PHASE3 MOTOR RPM 60Hz3520 VOLTAGE230/460 HERTZ60 SERVICE FACTOR1.15 AMBIENT TEMP C40 WEIGHT382 RPM RANGE3001-3600 DESIGN CODEA BEARING-DRIVE-END6311 BEARING-OPP-DRIVE-END6208 FL EFFICIENCY91.7 INSULATION CLASSF FL AMPS68/34 KVA-CODEJ 208V AMPS-- BRANDBaldor-Reliance DOE-CODE010A MANUFACTURER PART #EM4108T is_motorYes CUSTOMER-PART-NUMBER-- GREASEPOLYREX EM ENCLOSURE TYPETotally Enclosed SPACE-HEATER-AMPS-- SPACE-HEATER-VOLTS-- MAX. SPACE HEATER TEMP.-- POWER-FACTOR90 DRIVE END FLANGEStandard C-DIMENSION INCHES25.24 SERIAL-NUMBER-- POLES2 SPEC. NUMBER09F629Y842G1
