Baldor-Reliance, EM3616T-5, 7.5HP, 3470RPM, 3PH, 60HZ, 575V, 184T, 3646M, TEFC, F1

(No reviews yet) Write a Review

SKU:: SGB391493
UPC:
products.mpn
Condition:: New
Availability:: Usually Ships in 24 Hours
Shipping:: Calculated at Checkout
Warranty:: 1 year replacement Warranty. Details
Returns:: 30 Days Money Back Guarantee. Details

$1,472.58

Current Stock:

Quantity:

Adding to cart… The item has been added

Description
0 Reviews

Baldor-Reliance, EM3616T-5, 7.5HP, 3470RPM, 3PH, 60HZ, 575V, 184T, 3646M, TEFC, F1Features:Ball bearingsSuitable for mounting any positionHeavy gauge steel and cast iron framesTypical Applications:Pumps, compressors, fans, conveyors, machine tools and other applications where 575 volt three phase power is available. Product Specifications HORSEPOWER7 1/2 ENCLOSURETEFC FRAME184T MOUNTINGRigid NAMEPLATE RPM3450 PHASE3 MOTOR RPM 60Hz3450 VOLTAGE575 HERTZ60 SERVICE FACTOR1.15 AMBIENT TEMP C40 WEIGHT96 RPM RANGE3001-3600 DESIGN CODEA BEARING-DRIVE-END6206 BEARING-OPP-DRIVE-END6205 FL EFFICIENCY89.5 INSULATION CLASSF FL AMPS6.8 KVA-CODEJ 208V AMPS-- BRANDBaldor-Reliance DOE-CODE-- MANUFACTURER PART #EM3616T-5 is_motorYes ENCLOSURE TYPETotally Enclosed POWER-FACTOR93 DRIVE END FLANGEStandard C-DIMENSION INCHES18.04 SERIAL-NUMBER-- POLES2 SPEC. NUMBER36A001X881H1
